Does anyone have pictures of a Firecom 8500?

Fire Alarm General Discussion
21

Yeah: that’s been known about for a while I think. Very interesting indeed: might mean that there’s at least one 8500 system still in service in NYC!

1 Like
22

Oh yeah! That video was taken in the Duro-Dyne plant in New York. A lot eerier than the WTC7 whoop!

23

And I would totally not be surprised at all if there are at least some more older 8500 units in NYC that are at least still laying around in some buildings, either still sitting there as inactive/replaced or still in service. Especially in older buildings.

1 Like
24

Yeah: let’s just hope then that someone can successfully find & save them! (& hopefully also find that they’re in full working order too!)

1 Like
25

According to a friend of mine the initial photo Nick posted in this topic is of an Edwards/EST IRC-3, not a Firecom 8500, so I guess the hunt for even a mere picture of one is still on.

26

A CRT can be referenced in the following patent: US4342985A - Remote sensing and control system - Google Patents

I’m a bit new to this mystery, so please bear with me if my information is inaccurate.

27

Thanks for the information, and welcome to the forums!

28

Thanks! Happy to provide!

29

22c776d2a69df520f8fe03086f66f76d8057b275
22c776d2a69df520f8fe03086f66f76d8057b275711×399 157 KB

Here’s a possible photo of the desk-mount variant of the Firecom 8X. Credits to @Gary_Scott for finding this.

EDIT: It could also be a Comtrak 1720.

30

I also just realised this and I have never thought about this up until now…

Firecom 8X systems are basically wired the same way as your everyday security system! Just on a way larger scale. Security systems have a main box that is the brains of the system that has terminals for connecting devices to it. The “control panel” of an 8X connects the same way to a Terminal Transmitter Box (the brains of the system) as a security keypad would do.

And Radionics fire alarm systems wire the same way too. So I guess that Firecom had seen how security systems wire up and based their 8X systems off of that. Just a guess based on an observation.

31

Yeah, you might need to bring a 1-ton pickup truck with a tommy gate if you want to get one of those out of a building!

1 Like
32

Well that’s because a firecom 8000 seems to be a multiplex fire alarm system. You have a central panel, and remote transponders that have the circuits for zones and outputs. Stuff like ademco vista panels also use multiplex with remote transponders and everything.

33

That’s kinda what I said here but different.
