Yeah, I think CLIP devices poll red, with the possible exception of control modules.
1 Like
The S464A existed in an addressable version during the FS90 era.
There’s also some S464G1007’s (Honeywell-branded BG-12’s) in Terminal 1.
Also, the EST system was replaced with an XLS3000 (a rebranded Notifier NFS2-3030) over the past few years.
Or are you writing about Terminal 2?
I guess I was just writing about the whole airport in general but I did see that XLS-1000 annunciator. That’s good to know!
My info about the XLS3000 upgrade was about Terminal 1, so I’m assuming you were in Terminal 2.
1 Like
John Joseph Moakley United States Courthouse - Boston, MA
Pulls: Cerberus Pyrotronics MSI-10B’s
Detectors: ILI-1’s
Signals: SAE VA4 speaker/strobes
Danbury Fair Mall, Danbury, CT
This is a very weird and diverse system…
Main Mall:
Signals:
- Wheelock 7001T
- Wheelock 34T
- Wheelock AS
- System Sensor L-Series
- System Sensor SpectrAlert Advance
Macy’s:"
- Pulls: Simplex 4251-20s
- Signals: 2901-9833 horns (some on 2903 strobe plates)
- Detectors: Simplex “Wiffle-Ball” detectors
JCPenney:
- Pulls: Fire-Lite BG-12s
- Signals: System Sensor SpectrAlert Classic
Target:"
- Pulls: Fire-Lite BG-12s
- Signals: System Sensor L-Series
Olive Garden Restaurant Coon Rapids MN
Notifications
System Sensor P2RL Horn Strobes Wall Mounts and Ceiling Mounts
Pull Stations Notifier NBG12LX
Smithsonian National Museum of American History - Washington, D.C.
Panel: Siemens Addressable Panel (most likely an XLS since the entire system was recently upgraded)
Pulls: XMS-Ds
Detectors: OP921s (Some on DB-ADPTs, replacing FP-11s DI-3s, and a few DI-6s, and others newly installed) At least one FP-11 and one DI-6 (Not accessible during the upgrade so couldn’t be replaced, disconnected)
AVs: SET-CMC-CW-MNS-ALERTs, SET-CMC-W-MNS-ALERTs, SET-CWs, a few SLSCW-Fs, and a few SLSWW-Fs (Replacing silver Wheelock E90s)
1 Like
Biden Welcome Center (Delaware House Travel Plaza) - Newark, DE
Panel: EST Addressable Panel (What appears to be a QuickStart by the annunciators but I’m not so sure)
Pulls: SIGA-270s
Detectors: None (that are visible)
AVs: Genesis wall mount speaker/strobes and speakers as well as Integrity speaker/strobes outside
Frank Sinatra (Atlantic City) Service Area (Garden State Parkway) - Galloway Township, NJ
Panel: Siemens Addressable Panel
Pulls: HMS-Ds
Detectors: None (that are visible)
AVs: ZH-MC-Rs and ZR-MC-Rs
Update: Those empty junction boxes have indeed been filled… with GC-series remote speakers. Seems like they don’t want to rely solely on the PA anymore.
The remote strobes in those common areas were also replaced with G4-series strobes, and a few speaker/strobes.
The rest of the system, including the older Genesis speaker/strobes in tenant spaces, remains intact.
A renovated condominium unit also has a SIGA-HRD and, interestingly enough, Wheelock E90 speakers.
1 Like
Celia Cruz (Forked River) Service Area (Garden State Parkway) - Forked River, NJ
Panel: Notifier Addressable Panel (Likely an NFS-320)
Pulls: NBG-12LXes (Polling via FlashScan)
Detectors: None (that are visible)
AVs: P2RLs and SRLs
Melbourne Orlando International Airport (MLB) - Melbourne, FL
Panel: Notifier NFS2-3030 tied to a Simplex addressable panel
Pulls: NBG-12LXes
Detectors: TrueAlarms
AVs: SPSWLs, SPSCWLs, and at least one MASS (probably disconnected)
This is a very odd setup.
Did you see the simplex panel?
That looks like they’re in the midst of an upgrade. I’ve seen pictures of this airport, and they had 2901-9838 horns on 4903-9101 strobe plates.
I’ve been there twice over the past few months and nothing has changed but who knows
Palace Theater, Stamford, CT:
- Panel: EST3
- Pulls: SIGA-278s (EST branded)
- N/As: Genesis speaker strobes
- Detectors: SIGA-PSes
I heard something coming from a nearby building, and turns out it was this Siemens voice evacuation system (Desigo Fire Safety Modular or Cerberus Pro Modular) going off at the Aria Condominiums (this is in Naples, FL). I believe it was being tested. (it was silenced shortly after I started recording)
https://www.instagram.com/p/C5yU1zhrtSh/
1 Like
Well, if you thought the Danbury Mall had a weird system? Well, I present to you all two systems from Stamford, CT that are very diverse!
Ridgeway Mall, Stamford, CT:
Photos are available on my Google Photos album
This building is divided into three blocks: the Staples block (2391-2299 Summer Street), the Stop and Shop/Michael’s/Marshalls/Old Navy block (2200 Bedford St and 2233 Summer St), and the office block (which spans Sixth Street and some of Summer Street).
This is a map of the location (edited by me):
Now, I will explain each block’s systems. But first, we will introduce the panel.
Old Panels: Multiple EST IRC-3s (located at each building entrance and security office)
New Panels: EST3 (located in security office and at the Marshalls building entrance)
I- Staples Block :
Pulls:
- EST 270-SPO (current)
- Bosch-rebranded Sigcom T-Bar (old)
- Fire-Lite BG-10 (old)
N/As:
- Wheelock MT
- Gentex Commander 3 (old)
- System Sensor MASSADA (old)
- Edwards Integrity Speaker/Strobe
Detectors:
- Edwards GS photoelectric detectors
- System Sensor 2400-series detectors
II- Stop and Shop Block (divided by store):
Stop and Shop:
- Pulls: EST SIGA-278 (and one EST 276B)
- Alarms: EST Integrity Speaker/Strobes
- Detectors: Edwards GS photo detectors
Former Bed, Bath, and Beyond (same system is found in former DressBarn and Party City- but without the duct detectors and 405s)
Pulls: Edwards 270-SPO
- Alarms: Integrity Speaker Strobes and some EST 405 strobes
- Detectors: Edwards GS photo detectors
- Duct Detectors: Edwards duct detectors
- Other Components: IRC-3 annunciators at entrances to each store
Michael’s:
- Pulls: Fire-Lite BG-10s and BG-12s
- Alarms: SpectrAlert Classics
- Detectors: Either System Sensor 2400s or Edwards GS photo detectors
Marshall’s:
- Pulls: Edwards 270-SPOs
- Alarms: Integrity Speaker/Strobes
- Detectors: Edwards GS photo detectors
Drybar/Amazing Lash Studios (now closed) (AT&T has the same system):
- Pulls: Fire-Lite BG-12s
- Alarms: SpectrAlert Advances
- Detectors: Unknown (either i3s or Edwards GS photo detectors)
Old Navy:
- Pulls: Fire-Lite BG-12s
- Alarms: EST Integrity Speaker/Strobes
- Detectors: Unknown
Former Ashley Furniture (same system is found in Bevmax):
- Pulls: Edwards 270-SPOs
- Alarms: EST Genesis
- Detectors: SIGA-PSes
Starbucks:
- Pulls: Edwards 270-SPOs
- Alarms: EST Integrity Speaker Strobes
- Detectors: Edwards GS photo detectors
III- Summer/Sixth Street Office Block
Majority of the offices/small shops located here:
- Pulls: EST 270-SPOs
- Alarms: Integrity Speaker/Strobes
- Detectors: Edwards GS photo detectors
I do not know a lot about this section because a majority of this is abandoned or “employees only” areas. Also, the loading dock is here also.
Parking Garage:
- Pulls: Edwards 270-SPOs
- Alarms: Integrity Speaker/Strobes
- Detectors: Edwards GS photo detectors
Stamford Town Center, Stamford, CT:
Panel: A large Simplex panel (presumably a 4100U?)
I- Parking Garage
- Pulls: 4251-30s or 4251-20s
- Alarms: 4903 speakers on strobe plates
II- Main Mall (and most stores):
- Pulls: Simplex T-bars
- Alarms: TrueAlert wall or ceiling speaker/strobes
- Detectors: TrueAlarm detectors
III- Barnes and Noble/Former H&M
- Panel: EST3
- Pulls: GE and EST-rebranded SIGA-278s
- Alarms: Genesis horn/strobes
- Detectors: SIGA-PSes
IV- Macy’s
- Panel: Some sort of early Pyrotronics? panel
- Pulls: Pyr-A-Larm MS-51s
- Alarms: Vibratone 450s on AV32 plates, Wheelock MTs and some Wheelock MT horns on RSS strobe plates, and some SpectrAlert Advances
- Detectors: Chemtronics/Pyrotector detectors
V- Pickleball America
- Panel: Some Fire-Lite panel (?)
- Pulls: Fire-Lite BG-12s (Tyco-rebranded)
- Alarms: Advances
- Detectors: i3s
VI- Some Unique Restaurant Systems
-
The Capital Grille- Their system consists of SIGA-278s, Genesis horn/strobes, and SIGA-PS detectors
-
4th Quarter: Nothing unique, just a normal system with BG-12s and Advances
-
Peter Chang: I do not know, maybe the Simplex system?
-
Pieology: The Simplex mall system is hooked up here.
-
New York Comedy Club: Simplex mall system.
-
Terra Gaucha Brazilian Steakhouse: Simplex mall system as well.
VII- Movie Theater/Landmark Square Office Complex:
- Pulls: Simplex T-bars
- Alarms: TrueAlerts, 4903 speaker/strobes, or Cerberus Pyrotronics/Siemens speaker/strobes (theater lobby)
- Detectors: TrueAlarms
1 Like
Family Fare Supermarket- Mandan, ND
Panel- Potter PFC-4064 (Replaced the building’s original Simplex 4004 that died a few years ago).
Notification Appliances- One Simplex 4903 mechanical horn strobe at the front of the store. There is also a TrueAlert remote strobe in the pharmacy and 4903 remote strobes in the bathrooms.
Pull Stations- One Simplex 2099-9754 at the front service counter
Detectors- There are a few Simplex duct detectors and conventional TrueAlarms
Fails- The panel is at the main entrance and is currently completely blocked by a stack of extremely heavy cases of water bottles. There is also an extreme lack of notification coverage (especially strobe coverage) throughout the store. This is because the only notification appliance throughout the entire main area of the store is the one 4903 horn strobe. That is also the only horn in the building (at least in the areas that customers are allowed to access).
Note- This building was built in the late 90’s and is sprinklered.
